How To Install Ltspice On Linux Mint

Avatar for Noman Mohammad

By Noman Mohammad

Published on:

how to install ltspice on linux mint
Your rating ?

LTspice is a widely-used free circuit simulator. It is famous among engineers and hobbyists alike as it does not require any payment to use. Since LTspice is a Windows-based application, to run the software on Linux Mint, some settings must be tweaked. Not so hard-gladly this guide will help you out step-by-step.

Beginners as well as the advanced Linux users can follow along to set up LTspice on their Linux Mint systems hassle-free.

Why Install LTspice on Linux Mint?

Being reputed for stability and user-friendly interface, Linux Mint has become very popular with the professionals and hobbyists using circuit simulation tools like LTspice. While LTspice does not have a native port on Linux, it is possible to work on with Wine-a compatibility layer for running Windows applications.

  • With this guide, you will be able to:
  • Access an excellent circuit simulation tool.
  • Ease the installation process.
  • Use LTspice optimally on your Linux Mint system.

Step-by-Step Guide to Installing LTspice on Linux Mint

1. Update Your System

Before installing any software, ensure your Linux Mint system is up-to-date. This step minimizes compatibility issues.

sudo apt update && sudo apt upgrade -y

2. Install Wine

Wine is a crucial tool for running Windows-based applications on Linux. Install it using the following command:

sudo apt install wine-stable -y

Tip: Verify your Wine installation by running:

wine --version

You should see the installed Wine version displayed in your terminal.

3. Download LTspice

Visit the official LTspice download page and download the latest Windows executable file. Alternatively, use the command below to download it directly to your system:

wget https://ltspice.analog.com/software/LTspice64.exe -P ~/Downloads

4. Install LTspice Using Wine

Navigate to the directory where the installer is located and run it using Wine:

cd ~/Downloads
wine LTspice64.exe

Follow the on-screen instructions to complete the installation.

5. Run LTspice

Once installed, you can launch LTspice using the following command:

wine ~/.wine/drive_c/Program\ Files/LTC/LTspiceXVII/XVIIx64.exe

For convenience, consider creating a desktop shortcut or adding LTspice to your application menu.

FAQs on How to Install LTSpice in Linux

Can LTspice Be Installed Directly on Linux Mint?

No, LTspice is a Windows-based application. However, using Wine allows it to run seamlessly on Linux Mint.

What Is Wine, and Why Is It Needed?

Wine is a compatibility layer that enables Linux users to run Windows applications without a virtual machine or dual boot setup.

Where Are LTspice Files Stored?

When installed via Wine, LTspice files are stored in:

~/.wine/drive_c/Program Files/LTC/LTspiceXVII/
